150
152
154
156
158
160
162
164
166
168
170
172
174
176
178
180
182
184
186
188
190
192
194
196
198
200
Please be advised that this bicycle size chart is only a rough guide to help you select the correct frame size. We would always recommend visiting your local dealer to get measured and sized correctly, as although height is used, there are other factors which help determine the best frame size for you.
Stem Length plus Reach | 496 |
---|---|
Frame Seat Tube | 482 |
Frame Top Tube | 610 |
Frame Reach | 431 |
Frame Stack | 604 |
Frame Head Tube | 120 |
Frame Head Angle | 68 |
Frame Seat Angle | 73.5 |
Frame Chainstay | 450 |
Frame BB Drop | 60 |
Frame Wheel Base | 1146 |
Fork Offset | 44 |
Stem Length | 65 |
Handle Bar Width | 680 |
Frame Seat Tube | 431 |
Frame Top Tube | 590 |
Frame Reach | 411 |
Frame Stack | 604 |
Frame Head Tube | 120 |
Frame Head Angle | 68 |
Frame Seat Angle | 73.5 |
Frame Chainstay | 450 |
Frame BB Drop | 60 |
Frame Wheel Base | 1126 |
Fork Offset | 44 |
Stem Length | 65 |
Handle Bar Width | 680 |
Stem Length plus Reach | 516 |
Frame Seat Tube | 533 |
Frame Top Tube | 630 |
Frame Reach | 451 |
Frame Stack | 604 |
Frame Head Tube | 120 |
Frame Head Angle | 68 |
Frame Seat Angle | 73.5 |
Frame Chainstay | 450 |
Frame BB Drop | 60 |
Frame Wheel Base | 1166 |
Fork Offset | 44 |
Stem Length | 65 |
Handle Bar Width | 680 |
